Kubota DM5040
Features
Active Suspension
The Kubota DM5032, DM5040, and DM5028 have an exceptional ability to adapt to field conditions. The active suspension ensures even pressure across the entire cutterbar while in rough conditions. With 13.8" of upward suspension and 9.3" of downward adaption, these machines ensure that the cutting discs are always positioned close to the ground, ensuring outstanding cutting quality and trouble-free mowing.
The DM5000 Series floatation system protects the complete machine from possible shock loads. When an obstacle is encountered the cutterbar will pivot upward and over the obstacle and then automatically return once the obstacle has been passed.
Lateral Flotation
DM5000 series machines provide for 17 degrees of sideward adaption. This generates many benefits while working on hillsides or when aligning the unit on headlands.
Drawbar Swivel Hitch Gearbox
The drawbar swivel hitch gearbox is fixed to the mainframe in order to minimize movement during operation, yet it provides unlimited rotational movement between the machine and the tractor making it easier to perform sharp turns.
Counter
Rotating Three-Bladed Discs
With three blades per disc, Kubota mowers are constantly cutting. This means a third less load per blade, an even load on the drive and smoother power usage – which produces an even, cleanly cut stubble. Each steel blade is precisely angled to immediately discharge the cut crop upwards by both air flow and mechanical action.
Fully Welded Cutterbar
The fully welded Kubota cutterbar with overlapping C-channels makes for a stiff and strong design, ensuring a high level of durability. The cutterbar’s design, with machined gears and large bearings along with low oil requirements, allows for a low working temperature for efficient oil cooling and lubrication of the entire cutterbar.
Express Quick Change of Knives
Mowers can be fitted with the 'Express' system for quick and easy changing of knives. Simply place the lever around the bolt, release the spring by turning the lever and the knife is ready to be replaced with a new one.
Narrow Transport
DM5000 series offers a secure and convenient transport solution while still providing excellent road visibility. To make transportation width as narrow as possible, the side guards can be folded upwards. This reduces the transport width for DM5032 and DM5028 to only 9'10" while in the field it cuts a full 10'6". The transport width for DM5040 is reduced to 12'5" while in field it cuts 13'1".
Working Widths
- DM5032 / DM5028 – 10’6”
- DM5040 – 13’1”
Cutting Width ft. (m) | Cutting Width ft. (m)13' 1" | |
---|---|---|
Weight lbs. (kg) | Weight lbs. (kg)2778 | |
Transport Width ft. (m) | Transport Width ft. (m)12' 5" | |
Hitch (CAT) | Hitch (CAT)2 | |
Pin Hitch | Pin HitchStandard | |
PTO RPM | PTO RPM540 | |
Minimum PTO Horsepower Required HP/KW | Minimum PTO Horsepower Required HP/KW85 | |
Number of Disc and Knives | Number of Disc and Knives10/30 | |
Remotes | Remotes2 | |
Cutterbar Operating Angle | Cutterbar Operating Angle±17 | |
Stubble Height in. (mm) | Stubble Height in. (mm)1.79"-3.94" | |
BreakAway | BreakAwayNot Available | |
Non-Stop BreakAway | Non-Stop BreakAwayNot Available | |
Overrun Clutch | Overrun ClutchStandard | |
Swath Board (RH/LH) | Swath Board (RH/LH)Not Available | |
Swath Rollers (RH/LH) | Swath Rollers (RH/LH)Optional | |
High Skids +20/+40/+80 mm | High Skids +20/+40/+80 mmStandard / Optional / Optional | |
Lighting Kit | Lighting KitStandard |
